LLDPE Geomembrane Pond Liner
Smooth LLDPE liner
UV and chemical resistant
Cost-effectiveness
customized according to customer requirements.
Product Introduction
LLDPE smooth liner (Linear Low-Density Polyethylene)
MTTVS® LLDPE geomembrane is produced from linear low-density polyethylene resin (PE-LLD). The geomembrane has a density of 0.939g/㎤ or less. Compared with HDPE, LLDPE lining provides greater flexibility and extensibility. Has excellent resistance to low temperature and UV exposure. LLDPE Liners Designed for Waste Containment. High quality and low price, long life, high strength and durability. MTTVS® can provide linear low-density polyethylene geomembrane (GL-2 type) for environmental protection. The thickness ranges from 0.5mm to 3.00mm, with LLDPE Liners - Smooth and LLDPE Liners Texturedand it is also customized according to customer requirements.
Benefits of LLDPE Liners - Smooth:
● Superior flexibility
● UV and chemical resistant
● Puncture resistant
● Long performance and durability
Typical Applications:
● Effluent Ponds
● Exposed Ponds
● Storm Water Collections Ponds
● Waste Water
LLDPE Geomembrane (Linear Low-Density Polyethylene) | ||||||||||
Properties | TEST METHOD | UNIT ENGLISH(METRIC) | MINIMIUM AVERAGE ROLL VALUE ENGLISH(METRIC) | |||||||
GL-2 20mil LL | GL-2 30mil LL | GL-2 40mil LL | GL-2 50mil LL | GL-2 60mil LL | GL-2 80mil LL | GL-2 100mil LL | GL-2 120mil LL | |||
Thickness | ASTM D 5199 | mil(mm) | 20(0.50) | 30(0.75) | 40(1.00) | 50(1.25) | 60(1.50) | 80(2.00) | 100(2.5) | 120(3) |
Density | ASTM D 1505 | g/cm3 | 0.920 | 0.920 | 0.939 | 0.939 | 0.939 | 0.939 | 0.939 | 0.939 |
Strength at break | Dumbell,2 ipm | lb/in-width(N/mm) | 76/(13) | 114(20) | 154(27) | 188(33) | 240(42) | 302(53) | 377(66) | 457(80) |
Elongation at Break | G.L.2.0in(50mm) | % | ≥800 | ≥850 | ≥875 | ≥800 | ≥800 | ≥800 | ≥800 | ≥800 |
Tear Resistance | ASTM D 1004 | lb(N) | 11(50) | 16(71) | 22(100) | 27(120) | 33(150) | 45(200) | 56(250) | 67(300) |
Puncture Resistance | ASTM D 4833 | lb(N) | 30(130) | 46(205) | 56(250) | 69(310) | 90(400) | 112(500) | 139(620) | 168(750) |
Dimensional Stability | ASTM D 1204 | % | ±2 | ±2 | <2 | ±2 | ±2 | ±2 | ±2 | ±2 |
Carbon Black Content | ASTM D 1603 | % | >2/>2.5 | >2/>3.0 | >2.5 | >2/>3.0 | >2/>3.0 | >2/>3.0 | >2/>3.0 | >2/>3.0 |
Hydrostatic Resistance | ASTM D 751 | psi(kPa) | 118(814) | 175(1206) | 250(1724) | |||||
U.V.Resistance GRI-GM-11 | ASTM D 5885 | % | 35 | 35 | 35 | 35 | 35 | 35 | 35 | 35 |
Volatile Loss Method A | ASTM D 1203 | % | -1 | |||||||
Low Temp.lmpact Failure | ASTM D 746 | ℉(℃) | <-94(-70) | <-94(-70) | <-94(-70) | <-94(-70) | <-94(-70) | <-94(-70) | <-94(-70) | <-94(-70) |
Resistance to Soil Burial | ASTM D 3083 | % | ±10 | ±10 | ±10 | ±10 | ±10 | ±10 | ±10 | ±10 |
Environmental Stress Crack Resistance Hours to Failure | ASTM D 5397 | hrs | >400 | >400 | >400 | >400 | >400 | >400 | >400 | >400 |
Standard Oxidative Induction Time | ASTM D 3895,200℃;O2,1atm | mins | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 |
High pressure Oxidative Induction Time | ASTM D 5885 | mins | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 |
About MTTVS® factory
MTTVS® Geosynthetics Company specializes in the research, development, production, promotion and application of geosynthetics, and is the world's leading supplier of geosynthetics. Founded in 2014 and located in Shandong, China, it has ISO9001, ISO14001 and ISO45001 international authoritative management system certifications. It has strong strength. It has more than 10 international advanced equipment production lines and a large professional engineering and technical team. It has successfully integrated and developed core markets. Customers create maximum value. Through the processing of synthetic raw materials. We develop, manufacture and provide innovative and reliable geosynthetics to improve the performance of our customers' products. Our main business is the production and export of one-stop services and products such as geotextiles, geomembranes, geogrids, geocells, three-dimensional composite drainage nets, ecological bags, drainage boards, 3D geomats, etc.
Our products are exported to 56 countries around the world. Our main customers are from the United States, Germany, Pakistan, India, Kenya, Vietnam, Mirru, Ukraine, Uganda, Bolivia, Ecuador, Australia, France, Sweden, United Kingdom, Hong Kong, Hungary, New Zealand, Poland, Mexico, Brazil, Bangladesh , Thailand, Malaysia, Indonesia, Singapore, Philippines, Sri Lanka, UAE, Saudi Arabia, Qatar, Ghana, Ethiopia, Somalia, Nigeria, South Africa, Swaziland, Mongolia, etc.
Today, we not only manufacture the best quality geosynthetics products, but also provide professional design and installation services. OEM, ODM, custom development and manufacturing can also be provided. MTTVS® Geosynthetics is a strong brand manufacturer in the production, promotion and sales industry. By providing advanced solutions and products in various applications and markets worldwide, MTTVS® Geosynthetics continues to set industry standards and become the most important leader.
Welcome global industry partners to discuss cooperation!
MTTVS® geosynthetics you can trust
