0.5mm 0.75mm 1mm 1.5mm 2.0 mm Anti-Seepage Waterproof Impermeable Smooth High Density Polyethylene Geomembrane for Pond Landfill Water Reservoir Liner

Each of our non woven filter fabric, Geocomposite Dreinage Systems GDS , hdpe textured impermeable geomembrane saves energy, reduces consumption and pollutant emissions throughout the entire life cycle of design, manufacture, transportation, use, recycling, reuse and disposal. The company will reasonably apply talents, cultivate them and cherish them. Based on the business philosophy of 'Quality-based, Honesty-based, Credit-oriented', we carefully produce every product that customers need, and we can also tailor-made them according to the drawings or samples provided by customers to meet the requirements of them. The needs of our customers are the direction of our efforts, and the satisfaction of our customers is our unremitting pursuit. The never-ending innovation and improvement of management, technology, market, service and knowledge will continue to enhance the comprehensive competitiveness of our company and promote our sustainable development.

HDPE textured geomembranes double(single)

HDPE textured geomembranes are made of High density polyethelyne It mainly composed of high density polyethylene, carbon black and little amount of antioxidants and heat stabilizers. Available with either single- or double-sided textured surface.HDPE textured geomembrane owns good flexibility, excellent chemical stability, mechanical properties, environmental stress cracking resistance, dimensional stability and aging resistance, and also has the larger friction coefficient and good anti-sliding function. which exhibit superior shear strength and the highest multi-axial performance offered in the market. MTTVS^® textured geomembrane meets the industry-recognized ASTM D7466 standard.

The textured surface allows for increased interface strength against soils, textiles, geosynthetic clay liners (GCLs) and other critical interfaces. HDPE textured geomembrane is generally applied to the steep slope improvement and the projects which requires a large friction coefficient to improve the stability. and is very suitable for the slopes of landfill or steeply slope and vertical anti-seepage applications, and facilitates the secondary laying of the geotextile and enhances the deformation force of the geomembrane.

MTTVS^® Textured HDPE Geomembrane is widely applied for such projects which need increased frictional performance, flexibility and elongation between two layers and high steeper slopes as, mining, retaining backfills and waste containment. Our products have a proven history of success in many lining applications.

FEATURE

● Good flexibility

● For service temperature range: -70℃--+110℃

● Corrosion resistance, aging resistance

● Excellent environmental stress cracking resistance property

● High tensile strength and elongation

● Larg friction coefficient

● Great anti-sliding function

● Thickness: 1.0~2.5mm

● HDPE

APPLICATION

● Slopes of landfill or steeply slope

● Retaining backfills

● Waste containment.

● Municipal environmental projects

● Water conservancy projects

● Landfill cap(closures),

● Mining heap leach pads,coal ash pond, animal waste containment

● Waste water treatment lagoon, secondary containment

● Pond liner, canal linings, tank linings

● Vertical anti-seepage applications

● Solid waste landfills, Hazardous waste landfills

HDPE textured geomembranes specification

Properties	TEST METHOD	FREQUENCY	UNIT ENGLISH(METRIC)	MINIMIUM AVERAGE ROLL VALUE ENGLISH(METRIC)
				40mil HD	60mil HD	80mil HD	100mil HD
Thickness Lowest individual reading	ASTM D 5199	every roll	mil(mm)	40(1.00) 36(0.90)	60(1.50) 51(1.28)	80(2.00) 72(1.80)	100(2.50) 90(2.25)
Density	ASTM D 1505	200,000lb(90,000kg)	g/cm3	0.940	0.940	0.940	0.940
Tensile Properties(Each Direction)	ASTM D 6693,Type IV	20,000lb(9000 kg)
Strength at break	Dumbell,2 ipm		lb/in-width(N/mm)	60(10)	132(23.1)	120(21)	380(67)
Strength at yield			lb/in-width(N/mm)	84(15)	132(23.1)	168(29)	210(37)
Elongation at Break	G.L.2.0in(50mm)		%	100	350	100	700
Elongation at Yield	G.L.1.3in(33mm)		%	12	13	12	12
Tear Resistance	ASTM D 1004	45,000lb(20,000kg)	lb(N)	28(125)	45(200)	56(249)	70(311)
Puncture Resistance	ASTM D 4833	45,000lb(20,000kg)	lb(N)	60(267)	120(534)	120(534)	180(800)
Carbon Black Content	ASTM D 1603*4218	20,000lb(9000 kg)	%(range)	2.0-3.0	2.0-3.0	2.0-3.0	2.0-3.0
Carbon Black Dispersion	ASTM D 5596	45,000lb(20,000kg)		Note(1)	Note(1)	Note(1)	Note(1)
Asperity Height	ASTM D 7466	second roll	mil(mm)	18(0.45)	20(0.51)	18(0.45)	18(0.45)
Notched Constant Tensile Load	ASTM D 5397,Appendix	200,000lb(90,000kg)	hr	500	500	500	500
Oxidative Induction Time	ASTM D 3895,200℃;O2,1atm	200,000lb(90,000kg)	mins	>100	>140	>100	>100

About MTTVS^® factory

MTTVS^® Geosynthetics Company specializes in the research, development, production, promotion and application of geosynthetics, and is the world's leading supplier of geosynthetics. Founded in 2014 and located in Shandong, China, it has ISO9001, ISO14001 and ISO45001 international authoritative management system certifications. It has strong strength. It has more than 10 international advanced equipment production lines and a large professional engineering and technical team. It has successfully integrated and developed core markets. Customers create maximum value. Through the processing of synthetic raw materials. We develop, manufacture and provide innovative and reliable geosynthetics to improve the performance of our customers' products. Our main business is the production and export of one-stop services and products such as geotextiles, geomembranes, geogrids, geocells, three-dimensional composite drainage nets, ecological bags, drainage boards, 3D geomats, etc.

Our products are exported to 56 countries around the world. Our main customers are from the United States, Germany, Pakistan, India, Kenya, Vietnam, Mirru, Ukraine, Uganda, Bolivia, Ecuador, Australia, France, Sweden, United Kingdom, Hong Kong, Hungary, New Zealand, Poland, Mexico, Brazil, Bangladesh, Thailand, Malaysia, Indonesia, Singapore, Philippines, Sri Lanka, UAE, Saudi Arabia, Qatar, Ghana, Ethiopia, Somalia, Nigeria, South Africa, Swaziland, Mongolia, etc.

Today, we not only manufacture the best quality geosynthetics products, but also provide professional design and installation services. OEM, ODM, custom development and manufacturing can also be provided. MTTVS^® Geosynthetics is a strong brand manufacturer in the production, promotion and sales industry. By providing advanced solutions and products in various applications and markets worldwide, MTTVS^® Geosynthetics continues to set industry standards and become the most important leader.

Welcome global industry partners to discuss cooperation!

MTTVS^® geosynthetics you can trust.

We are committed to fostering and forming a batch of 0.5mm 0.75mm 1mm 1.5mm 2.0 mm Anti-Seepage Waterproof Impermeable Smooth High Density Polyethylene Geomembrane for Pond Landfill Water Reservoir Liner that master key technologies and have strong brand influence. We have been adhering to the values of "honesty and enterprise, people-oriented, technology-led, and continuous innovation", and are always in a state of steady and rapid development. We use the policy of "people-oriented, respect for knowledge and talent" to achieve the harmonious development of people, enterprises and society.
