LLDPE ENVIRONMENTAL GEOMEMBRANE LINER

MTTVS^® LLDPE geomembrane is produced from linear low-density polyethylene resin (PE-LLD). Compared with HDPE, LLDPE lining provides greater flexibility and extensibility. Has excellent resistance to low temperature and UV exposure.LLDPE Liners Designed for Waste Containment. High quality and low price, long life, high strength and durability. MTTVS^® has LLDPE Liners - Smooth and LLDPE Liners Texturedand. If the project needs to improve friction, flexibility and elongation, MTTVS^® Linear low density polyethylene (LLDPE) lining-textured geomembrane is the best product choice. Its textured surface adds friction and a steeper slope concept.MTTVS^® can provide linear low-density polyethylene geomembrane (GL-2 type) for environmental protection. It is available in 20 mil, 30 mil, 40 mil, 50mil 60 mil, 80mil, 100mil, 120mil thicknesses. it is also customized according to customer requirements.

To request one of our free Product Sample Books, please email your name, phone number, and address to: sales@mttvs.com

Benefits of LLDPE LIners - Textured:

● Increased frictional resistance

● Exellent flexibility and elongation

● UV resistan

● Chemical resistant

● Puncture resistant

● Long performance and durability

Typical Applications:

● Effluent Ponds lining

● Exposed Ponds lining

● Storm Water Collections Ponds

● Waste Water and Waste Containment

● Landfill Caps

● Solid Waste Landfills

● Hazardous Waste Landfills

● Mining

● Coal ash pond

LLDPE GEOMEMBRANE LINER Specification:

Properties	TEST METHOD	UNIT ENGLISH(METRIC)	MINIMIUM AVERAGE ROLL VALUE ENGLISH(METRIC)
			MTTVS 20mil LL	MTTVS 30mil LL	MTTVS 40mil LL	MTTVS 60mil LL
Thickness	ASTM D 5199	mil(mm)	20±10%(0.50)	30±10%(0.75)	41.5(1.04)	60(1.50) 54(1.35)
Density	ASTM D 1505	g/cm3	0.920	0.920	0.939	0.939
Strength at break	Dumbell, 2 ipm	lb/in-width(N/mm)	76/(13)	114(20)	185(32)	240(42)
Elongation at Break	G.L.2.0in(50mm)	%	800	850	875	800
Tear Resistance	ASTM D 1004	lb(N)	11(49)	16(71)	27(120)	37(165)
Puncture Resistance	ASTM D 4833	lb(N)	30(130)	46(205)	75(333)	90(400)
Dimensional Stability	ASTM D 1204	%	±2	±2	<2	2-3
Carbon Black Content	ASTM D 1603	%	>2/>2.5	>2/>3.0	>2.5
Hydrostatic Resistance	ASTM D 751	psi(kPa)	118(814)	175(1206)	250(1724)
U.V.Resistance GRI-GM-11	ASTM D 5885	%	35	35	-
Volatile Loss Method A	ASTM D 1203	%	-	-	<1
Low Temp.lmpact Failure	ASTM D 746	℉(℃)	<-94(-70)	<-94(-70)	<-94(-70)
Shop Shear Seam Strength	ASTM D 4545	lb/in(kN/m)	40(7.0)	42(7.3)
Shop Peel Seam Strength	ASTM D 4545	lb/in(kN/m)	30(5.3)	35(6.1)
Resistance to Soil Burial	ASTM D 3083	%	-	-	±10
Environmental Stress Crack Resistance Hours to Failure	ASTM D 5397	hrs	-	-	>400
Perms	ASTM E96	grains/ft2/hr/in/Hg.	-	-	0.022
Bonded Seam Strength	ASTM D 4645	lbf/in-width(N/mm)	-	-	80(356)
Seam Peel Adhesion	ASTM D 4645	lbf/in-width(N/mm)	-	-	69(307)
Oxidative Induction Time	ASTM D 3895, 200℃, 1atm O2	minutes			≥140

About MTTVS^® factory

MTTVS^® Geosynthetics Company specializes in the research, development, production, promotion and application of geosynthetics, and is the world's leading supplier of geosynthetics. Founded in 2014 and located in Shandong, China, it has ISO9001, ISO14001 and ISO45001 international authoritative management system certifications. It has strong strength. It has more than 10 international advanced equipment production lines and a large professional engineering and technical team. It has successfully integrated and developed core markets. Customers create maximum value. Through the processing of synthetic raw materials. We develop, manufacture and provide innovative and reliable geosynthetics to improve the performance of our customers' products. Our main business is the production and export of one-stop services and products such as geotextiles, geomembranes, geogrids, geocells, three-dimensional composite drainage nets, ecological bags, drainage boards, 3D geomats, etc.

Our products are exported to 56 countries around the world. Our main customers are from the United States, Germany, Pakistan, India, Kenya, Vietnam, Mirru, Ukraine, Uganda, Bolivia, Ecuador, Australia, France, Sweden, United Kingdom, Hong Kong, Hungary, New Zealand, Poland, Mexico, Brazil, Bangladesh , Thailand, Malaysia, Indonesia, Singapore, Philippines, Sri Lanka, UAE, Saudi Arabia, Qatar, Ghana, Ethiopia, Somalia, Nigeria, South Africa, Swaziland, Mongolia, etc.

Today, we not only manufacture the best quality geosynthetics products, but also provide professional design and installation services. OEM, ODM, custom development and manufacturing can also be provided. MTTVS^® Geosynthetics is a strong brand manufacturer in the production, promotion and sales industry. By providing advanced solutions and products in various applications and markets worldwide, MTTVS^® Geosynthetics continues to set industry standards and become the most important leader.

Welcome global industry partners to discuss cooperation!

MTTVS^® geosynthetics you can trust

The Construction Material HDPE, LDPE, LLDPE Geomembrane for Environment Protection produced by our company are manufactured in accordance with international standards, and the quality is absolutely guaranteed. In order to keep up with the pace of the times, we continue to optimize and perfect our products. We give full play to the dual role of salary guarantee and performance assessment to achieve optimal allocation of talent structure.
