HDPE Geomembranes Pond Liner 2.0mm
Thickness:2.0mm Width:2m-12m Color:Black,Green,Blue,White Material:HDPE Anti aging, anti ultraviolet, high barrier Application: Oil and Gas:Chemical plant,refinery,oil storage tank etc. Solid or liquid waste treatment. Water conservancy Project. Aquaculture Mining
Product Introduction
HDPE Geomembranes Pond Liner 2.0mm for Landfill
MTTVS 2.0mm HDPE Geomembrane liner is manufactured by the high quality quality Polyethylene virgin raw material,adding carbon black,antioxidant,anti-aging and UV resistance component.MTTVS have the first class automatic blowing film production line and flat die production line.And geomembrane is an effective waterproofing barrier in project.MTTVS have smooth,textured and composite Geomembrane with black,white,green and blue color etc.
Yield strength>29kN/m, breaking strength>53kN/m, puncture resistance strength>800N,Stress Crack Resistance >500hr. The Standard Oxidation Induction Time is 100min, and the High Pressure OIT is 500min. Melt Index ,condition 190℃/2.16kg :0.20g/10min.
Table-High Density Polyethylen(HDPE）Geomembrane - Smooth：
| Properties | Test Method | Test Value | Testing Frequency (minimum) | |||||||
| 0.5mm | 0.75mm | 1.0mm | 1.25mm | 1.5mm | 2.0mm | 2.5mm | 3.0mm | |||
| Thickness - (min.ave.) - mm ● lowest individual of 5 values ± % | D 5199 | nom. ±5 | nom. ±5 | nom. ±5 | nom. ±5 | nom. ±5 | nom. ±5 | nom. ±5 | nom. ±5 | per roll |
| Formulated Density (min.ave.) - g/cc | D 1505 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 90,000kg |
| Tensile Properties (min.ave.) ● yield strength - kN/m ● break strength - kN/m ● yield elongation - % ● break elongation - % | D 6693 Type IV | 9 17 12 700 | 11 20 12 700 | 15 27 12 700 | 18 33 12 700 | 22 40 12 700 | 29 53 12 700 | 37 67 12 700 | 44 80 12 700 | 9,000kg |
| Tear Resistance (min.ave.) - N | D 1004 | 80 | 93 | 125 | 156 | 187 | 249 | 311 | 374 | 20,000kg |
| Puncture Resistance (min.ave.) - N | D 4833 | 200 | 240 | 320 | 400 | 480 | 640 | 800 | 960 | 20,000kg |
| Stress Crack Resistance - hr. | D 5397 App. | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | per GRI GM-10 |
| Carbon Black Content(range) - % | D4218 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 9,000 kg |
| Oxidative Induction Time(OIT)（min.ave.) (a) Standard OIT - min. — or — (b) High Pressure OIT - min. | D 8117 D5885 | 100 400 | 100 400 | 100 400 | 100 400 | 100 400 | 100 400 | 100 400 | 100 400 | 90,000kg |
| Oven Aging at 85℃ (a) Standard OIT (min.ave.) - % retained after 90 days — or — (b)High Pressure OIT (min.ave.) - % retained after 90days | D 5721 D8117 D5885 | 55 80 | 55 80 | 55 80 | 55 80 | 55 80 | 55 80 | 55 80 | 55 80 | per each formulation |
| UV resistance (a) Standard OIT (min.ave.) — or — (b)High Pressure OIT （min.ave.) - % retained after 1600 hrs | D 7238 D8117 D5885 | N.R.(8) 50 | N.R.(8) 50 | N.R.(8) 50 | N.R.(8) 50 | N.R.(8) 50 | N.R.(8) 50 | N.R.(8) 50 | N.R.(8) 50 | per each formulation |
| Melt Index,condition 190℃ c/2.16kg | D 1238 | 0.20g/10min | ||||||||
| Roll Width | 1-12m | |||||||||
| Roll Length | 50m or 100m | |||||||||
| Color | Black,Green,Blue,White | |||||||||
| Material: | HDPE, LDPE and LLDPE can be customized, |
Application:
- 2.0mm HDPE geomembrane liner is basically used for landfill leachate lagoon coverage.
2.0mm HDPE geomembrane liner for covering biogas digester.
2.0mm HDPE geomembrane liner is used for anti leakage paving construction of the bottom and slope of the new reservoir area of biogas digester and waste landfill.
2.0mm HDPE membrane is used for oilfield mud pit.
2.0mm HDPE geomembrana liner is used for emergency treatment pool.
2.0mm anti-seepage membrane is used for oil storage tank farm.
2.0mm HDPE geomembrane is used for anti-seepage of chemical workshop foundation (laying 2.0mm HDPE geomembrane, binding reinforcement cage and pouring concrete).
Foundation seepage prevention of 2.0mm HDPE geomembrane workshop.
Waterproofing of 2.0mm HDPE geomembrane dump.
2.0mm HDPE geomembrane regulating tank covering film.
Seepage prevention of 2.0mm HDPE geomembrane dump.
2.0mm HDPE geomembrane liner biogas digester black film cover.
2.0mm HDPE membrane for Oil and Gas:Chemical plant,refinery,oil storage tank etc.
2.0mm HDPE liner as Solid or liquid waste treatment:Landfill,waster water plant,industrial or hospital waste treatment site anti-seepage.
2.0mm pond liner for Water conservancy project:river embankment,lake dam,tailing dam,sewage dam and reservoir,channel,vertical wall,slope protection seepage control.
As for the specifications and price list of geomembrane？
How much is the price per square meter of geomembrane？
What is the price of geomembrane and composite geomembrane？
How much is the construction cost of geomembrane？
How much is the hdpe geomembrane per square meter？
How much is the cost of laying geomembrane per square meter？
How much is the labor cost of building membrane laying？
How long is the delivery time of geomembrane？
Please contact me sales@mttvs.com for relevant technical questions.
