Tri-Dimension Composite Geonet for Drainage of Landfill

We provide our customers with consistently high quality Geocells, Drainage Board, Flexible Permeable Hose through a high degree of automation, efficiency and attention to detail. 'Serving customers with heart' is our service tenet, and we use perfect pre-sales, in-sales and after-sales service to satisfy customers. We build our team into a learning organization, strengthen the training and education of our employees in terms of knowledge, skills, attitudes and concepts, cultivate complex talents, and realize the common development of our employees and the company. With excellent products, reasonable prices, timely supply, and thoughtful service, we have won wide recognition in the industry and the trust of customers, and continue to maintain the company's long-term and stable development.

Pit plastic composite drainage board

Sheet Drain, also called Drainage sheet, is a composed by HDPE drainage board and thermally bonded with needle-punched filament nonwoven filter geotextile fabric on the backside providing higher compressive strength. The geotextile fabric allows water to pass into the drain core while restricting the movement of soil particles that might clog the core. Metal pins, construction adhesives or double sided tape are applied to attach sheet drain to waterproofing material, concrete or wood. Sheet drain is widely used for large surface drainage. It can be used vertical for green roof, retaining walls, underground buildings, roofing and decks with the function of drainage and filtration.

FEATURE

● Virgin HDPE and geotextile material

● Can be vertical or horizontal installed

● Enhanced waterproof capability

● Chemical resistant

● Strong and durable

● Dual characteristics of HDPE and geotextiles

● High compressive strength

● Good filtering performance

● Excellent performance of drainage and water accumulation

● Good wear resistance

● Light weight and easy to transport

● Quick and convenient installation

Sheet Drain Applications

● Greening projects. Garden roof, vertical greening, sloping roof greening, football field, golf course, etc.

● Municipal Engineering. Airport, road subgrade, subway, tunnel, landfill.

● Construction Engineering. The upper or lower floor of the building foundation, the wall and floor of the underground indoor and outside, the roof, the roof seepage prevention and the heat insulation layer, etc.

● Water conservancy project. Reservoir seepage prevention, reservoir, artificial lake seepage prevention.

● Traffic engineering. highway, railway subgrade, embankment and slope protection layer.

Pit plastic composite drainage board specification

Property	Unit	BDS08	BDS10	BDS12	BDS12-2	BDS16
Core Properties	-	Virgin HDPE
Core Structure	-	Single Cuspated Flat Back
Core Height	mm	8	10	12	12	16
Material Thickness	mm	1.0	1.0	1.2	1.2	1.2
Geotextile Properties
Material Type	-	PET Filament geotextile
Structure	-	Needle Punched Heat Pressed
Weight	g/2㎡	200	200	200	250	200
Colour	-	White
Drainage Sheet Properties
Discharge Capacity	L/m/min	145	145	155	185
Break Elongation	%	25
Compressive Strength	kPa	250	280	260	310	280
Roll Width	m	3	3	3	3	3
Roll Length	m	30	30	20	20	20

About MTTVS^® factory

MTTVS^® Geosynthetics Company specializes in the research, development, production, promotion and application of geosynthetics, and is the world's leading supplier of geosynthetics. Founded in 2014 and located in Shandong, China, it has ISO9001, ISO14001 and ISO45001 international authoritative management system certifications. It has strong strength. It has more than 10 international advanced equipment production lines and a large professional engineering and technical team. It has successfully integrated and developed core markets. Customers create maximum value. Through the processing of synthetic raw materials. We develop, manufacture and provide innovative and reliable geosynthetics to improve the performance of our customers' products. Our main business is the production and export of one-stop services and products such as geotextiles, geomembranes, geogrids, geocells, three-dimensional composite drainage nets, ecological bags, drainage boards, 3D geomats, etc.

Our products are exported to 56 countries around the world. Our main customers are from the United States, Germany, Pakistan, India, Kenya, Vietnam, Mirru, Ukraine, Uganda, Bolivia, Ecuador, Australia, France, Sweden, United Kingdom, Hong Kong, Hungary, New Zealand, Poland, Mexico, Brazil, Bangladesh , Thailand, Malaysia, Indonesia, Singapore, Philippines, Sri Lanka, UAE, Saudi Arabia, Qatar, Ghana, Ethiopia, Somalia, Nigeria, South Africa, Swaziland, Mongolia, etc.

Today, we not only manufacture the best quality geosynthetics products, but also provide professional design and installation services. OEM, ODM, custom development and manufacturing can also be provided. MTTVS^® Geosynthetics is a strong brand manufacturer in the production, promotion and sales industry. By providing advanced solutions and products in various applications and markets worldwide, MTTVS^® Geosynthetics continues to set industry standards and become the most important leader.

Welcome global industry partners to discuss cooperation!

MTTVS^® geosynthetics you can trusted.

In the market competition, our company actively obtains and maintains the competitive advantage of Tri-Dimension Composite Geonet for Drainage of Landfill distribution channel. Management idea refers to the idea of guiding the production and operation activities of an enterprise according to what kind of business ideas, values, codes of conduct, etc. We provide better product cost performance, faster response speed and more professional value-added services than our competitors.
